LDAP查询过滤语法LDAPFilterSyntaxLDAP Filter SyntaxThis topic deals with the syntax and rules for an LDAP filter, which is a normal string which expresses the criteria for thefilter. You need knowledge about LDAP filters if you want to search objects and filter objects in the LDAP browser can get even more information about LDAP filters in the .Basic LDAP Filter Syntax and OperatorsLDAP filters consist of one or more criteria. If one than more criterion exist in one filter definition, they can be concatenatedby logical AND or OR operators. The logical operators are always placed in front of the operands (i.e. the criteria). This is theso-called ''.
The search criteria have to be put in parentheses and then the whole term has to be bracketed one more Operation:
(& (...K1...) (...K2...)) or with more than two criteria: (& (...K1...) (...K2...) (...K3...) (...K4...))OR Operation:(| (...K1...) (...K2...)) or with more than two criteria: (| (...K1...) (...K2...) (...K3...) (...K4...))
Nested Operation:Every AND/OR operation can also be understood as a single criterion:(|(& (...K1...) (...K2...))(& (...K3...) (...K4...))) means: (K1 AND K2) OR (K3 AND K4)The search criteria consist of a requirement for an LDAP attribute, e.g. (givenName=Sandra). Following rules should beconsidered:
Equality:Negation:Presence:Absence:Greater than:Less than:(attribute=abc) , e.g.
(&(objectclass=user)(displayName=Foeckeler)(!(attribute=abc)) , e.g.
(!objectClass=group)(attribute=*) , e.g.
(mailNickName=*)(!(attribute=*)) , e.g.
(!proxyAddresses=*)(attribute>=abc) , e.g.
(mdbStorageQuota>=100000)(attribute<=abc) , e.g.
(mdbStorageQuota<=100000)Proximity:Wildcards:(attribute~=abc) , e.g.
(displayName~=Foeckeler)
Caution: ~= is treated as = in ADS environments !!e.g. (sn=F*) or (mail=*@) or (givenName=*Paul*)Further rules:
Real attributes onlyOnly standard attributes can be used for LDAP filters. When specifying an LDAP search filter, you cannot useobject properties of the ADSI objects that aren't LDAP database attributes but interface properties of theregarding object. A list of the affected properties can be viewed in the SelfADSI Scripting Tutorial under thetopic ''.No quotation marksComparative strings do NOT appear in quotation marks. A filter for the displayName 'Philipp Foeckeler' wouldread as follows:
(displayName=Philipp Foeckeler).
Upper/lower caseIf you want to filter boolean attributes the consideration of the upper/ lower case will be crucial. The use ofTRUE or
FALSE is absolutely necessary for filtering such booleans. However, most other string attributes arecase-insensitiv, i.e. a hit will be found even if the upper and lower case differs from your search filter.
Especially in Exchange 5.5 directories most of the attributes are case sensitive. There are only few exceptionswhich can be viewed under the SelfADSI Scripting Tutorial topic ''.
DN-String attributesRegarding match algorithms of LDAP filters, LDAP directory systems comply with the specifications of theoriginal X.500 standards. According to these matching rules you can't use wildcards in LDAP filters forattributes containing LDAP distinguished names (attributes with DN-string syntax / ADSI attribute data typeADSTYPE_DN_STRING = 1). The same applies for ADS: Filters in which DN attributes are searched with wildcardsdo not work.
This can be quite irritating. You can' search for all users that are members in groups that contain a certainstring in their group names. The reason for this is that the user attribute memberOf has the data type more important could be the search for objects in a specific OU. Especially, when only the declaration of apure filter string is allowed and when there is no possibility to specify the search base of an LDAP search. Thismight well be for the definition of recipient policies in Microsoft Exchange environments. Thus, thefollowing filter won't work! (distinguishedName=*,ou=Sydney,dc=cerrotorre,dc=org)
In this case we have to use a script-based solution which provides a workaround for this LDAP filter l charactersLDAP filters can be specified by unicode characters. You may, for example, use German umlauts - if it makessense (if the filtered attribute is an unicode string). However, the characters ( ) & | = ! > < ~ * / play a specialrole for the declaration of LDAP you search for or want to compare these characters within an attribute string, you'll have to use a prefixedbackslash and the corresponding hexadecimal ASCII code:(|
)=~293d7e5c
&>*
263e2a An example: We want to retrieve all objects whose attributes "displayName" start with "*" : (displayName=2a)
The character zero (00) may also be It's also possible to filter for certain values in multivalue attributes. An example is the attribute objectClass. Dueto the hierarchical structure of the directory schema, an object will always be an instance of several objectclasses. An ADS is an object of the class types
top,
person,
organizationalPerson und
user. Thus, afilter could be: (objectClass=user)
However, you need to take into consideration that such filtering always costs more server performance than anordinary 'one-dimensional' attribute search ing for Hex Numbers and Binary Values
Hex NumbersIn cases where attributes of the type integer or long integer are compared and filtered for specific hex numbers,the correspondent decimal coded number has always to be used in the LDAP filter. An example: If you look forlocal security groups in the ADS following two flags will have to be set for the groupType attribute:ADS_GROUP_TYPE_LOCAL_GROUP (0x00000004)ADS_GROUP_TYPE_SECURITY_ENABLED (0x80000000)The addition of these values is the hex value 0x80000004, calculated in the decimal number 2147483652 - this hasto be used in the LDAP filter: (groupType=2147483652)Binary ValuesIt's a completely different thing if you want to compose filters for attributes whose data types appear as binaryhex values (the according data type is often referred to as 'Octet String').If you are going to filter for such binary attributes, it is mandatory to declare every single byte that has to becompared in hex code. For instance, if you search for objects with the attribute 'Inventory' which has the value0x01AAF5EF, then the appropriate filter will have to read: (Inventory=01aaf5ef)Unfortunately, wildcard search is not allowed when searching for binary attributes!
Filtering for Bit FieldsBy using LDAP filters it's also possible to find objects for which a specific bit either is or is not set within a bit field. In thiscase, an strange looking syntax has to be followed:
LDAP_MATCHING_RULE_BIT_AND 1.2.840.113556.1.4.803 LDAP_MATCHING_RULE_BIT_OR 1.2.840.113556.1.4.804
An example:For the attribute 'groupType' following bit mask is important in ADS group objects:ADS_GROUP_TYPE_GLOBAL_GROUP = 0x00000002ADS_GROUP_TYPE_LOCAL_GROUP = 0x00000004ADS_GROUP_TYPE_UNIVERSAL_GROUP = 0x00000008ADS_GROUP_TYPE_SECURITY_ENABLED = 0x80000000A filter for universal groups has to search for those objects in whose attributes the 4th least significant bit is set. This canbe checked by equating the attribute of the value 0x00000008 (this represents the 4th bit) in an AND filter:'All universal groups:
(groupType:1.2.840.113556.1.4.803:=8)
Caution: In LDAP filters the hex value of the bit filter must be decimal at this point! So if all security groups (and not thedistribution groups) are to be found, it has to be filtered for the 8th bit (0x80000000 = 2147483648):
'All security enabled groups:
(groupType:1.2.840.113556.1.4.803:=2147483648)An example for an OR filter: We search all users which don't need a password (userAccountControl is set on 0x20 - 32) orwhose passwords never expires (userAccountControl is set on 0x10000 = 65536). So we have to build a filter with thevalue 65568 (=65536 + 32):
'All users which don't need a password OR whose passwords don't expire:
(userAccountControl:1.2.840.113556.1.4.804:=65568)
Please note that bit-wise filtering is a much more complex procedure for a server. For this reason you should take intoconsideration the use of normal equity criteria. If for universal security groups, the two flags 0x80000000 and0x00000008 can be added up and then be filtered for the according decimal value 2147483656:
'All universal security groups:
(groupType=2147483656)
Please note that the LEX let's you set such bitmap filter syntaxes very ing with Ambiguous Name Resolution (ANR)
The Ambiguous Name Resolution is able to find users or contacts in Active Directory environments whose names are onlypartly known. In this case not only the object name but also the display name, first and last name as well as the diverse mailaddresses are involved in the search. As an Outlook user you can have a look at the ANR filtering search by theoption 'Check names' for getting the best hit while searching for an address.
Which attributes are integrated exactly in the ANR search is specified by the attribute search flags in the directory doing so, a so-called ANR set of attributes is declared. Following attributes are part of the ANR set by default:Relative Distinguished Name (RDN), this could be for example the values for
cn=.... or
ou=...givenName (first name)sn (last name)displayName (display name)legacyExchangeDN (after migrations the Exchange 5.5 directory name of the old mailbox is shown here)proxyAddresses (mail addresses)physicalDeliveryOfficeName (office address)The syntax of ANR filters is as follows:
(anr=Philipp) or (anr=p f) or (anr=Foeck)All these filters would find the user 'Foeckeler, Philipp'. The second one is able to find 'Philipp Foeckeler' as well as 'FritzPaul'. This is because the ANR filter checks the first name and last name in both directions.
